Combining the best of both worlds, the Solo Studio Multi-Voice Channel Strip allows users to choose between a pristine low-noise/low-distortion solid state transistor circuit a and a warmer Class-A tube mic preamp. Along with the flexible Tilt EQ control, users can voice the Solo Studio to create their own signature sound. Featuring 48V phantom power, a front Microphone/Line balanced input or a high impedance Instrument input, users can tailor the Solo Studio to suit any sound source. A Low-Cut control allows vocals to be sculpted for clarity while the Tilt EQ can be used to emphasize high presence or low-end warmth. The Solo Series of single channel rackmount units have been developed for the recording enthusiast with a preference for simplicity.
Frequency Response 15 Hz to 50 kHz (+0, -1dB)
Dynamic range >110dB ("A" weighted)
CMRR >90dB
THD <0.005% (typical)
Equivalent Input Noise -129dBu (XLR, "A" weighted)
Maximum Input Level +19dBu (XLR)
Maximum Instrument Input +17dBu
47k ohms (XLR),
Input Impedance
>800k ohms (Instrument)
Maximum Output Level) +27dBu (XLR
Output Impedance 47 ohms (XLR)
Maximum Gain 55dBMeter
Attack Time 0.25msec. to 50msec. variable
Release Time 150msec. to 3sec. variable
CMRR >90dB THD <0.005% (typical
OVU = +4dBu output (+4dBu mode)
Calibration
OVU = -10dBV output (-10dBV mode)
Low Cut Filter single pole, 80Hz
Tilt EQ +/- 3dB adjustable
Power Requirements 100-240V 50Hz/60Hz
(HxWxD)
1.75-inch x 19-inch x 6.0-inch
Dimensions:
4.45 cm x 48.3 cm x 15.2 cm
Weight 5.6 lb / 2.5kg
(HxWxD, inches)
5" x 20.4" x 7.44"
Box Dimensions
12.6 cm X 51.8 cm x 18.9 cm X
